لایه

استانداردهای پورت

Number of Queues per port

MAC-address table

پشتیبانی از D-LINK Green

0.71kg

دی لینک-D-Link

هوشمند

8 پورت گیگ

8پورت

دارد

ندارد

IEEE 802.3 compliant, IEEE 802.3u compliant, IEEE 802.3ab compliance, Supports Half/Full-duplex operation at 10/100Mbps, Supports Full-duplex operation at 1000Mbps, Supports Auto-Negotiation for each port, Auto MDI/MDIX, IEEE 802.3x Flow Control support, IEEE 802.3az compliant, IEEE 802.3 compliant, IEEE 802.3u compliant, IEEE 802.3ab compliance, Supports Half/Full-duplex operation at 10/100Mbps, Supports Full-duplex operation at 1000Mbps, Supports Auto-Negotiation for each port, Auto MDI/MDIX, IEEE 802.3x Flow Control support, IEEE 802.3az compliant

16Gbps

Store and Forward

8K Entries

2Mbits

POE 802.3af

64W

ماکزیمم میزان مصرف برق

7.88 Watts

ابعاد

7.4” x 4.7” x 1.1”, (190mm x 120 mm x 28mm)

Power (Per Device), PoE Max. (DGS-1100-08P Only), Link/Activity/Speed (Per Port)

FCC Class A, CE Class A, VCCI Class A

Flow Control, – 802.3x Flow Control, – HOL Blocking Prevention, IGMP Snooping, – IGMP v1/v2 Snooping, – Supports 32 Groups, Loopback Detection, Link Aggregation, – 1 group, 2-4 ports per group (DGS-1100-05), – 2 groups, 2-4 ports per group (DGS-1100-08/08P), – 8 groups, 2-4 ports per group (DGS-1100-16/24), • Port Mirroring, – One-to-One, – Many-to-One (DGS-1100-16/24 only), • Cable Diagnostics, • Statistics, – Tx Ok, – Tx Error, – Rx Ok, – Rx Error

Port-based VLAN, 802.1Q Tagged VLAN, Surveillance VLAN, Voice VLAN, • Management VLAN, • VLAN Group, – Supports 32 static VLAN groups, – Max. 4094 VIDs

802.1p Quality of Service, 4 queues per port, Queue Handling, – Strict, – Weighted Round Robin (WRR), • Bandwidth Control, – DGS-1100-05/08/08P Port Based, (Ingress/Egress, min. granularity 8 kb/s), – DGS-1100-16/24: Port Based, (Ingress/Egress, min. granularity 64 kb/s)

Static MAC Address, – Max. 32 entries (DGS-1100-05/08/08P), – Max. 128 entries (DGS-1100-16/24), • Broadcast/Multicast/Unknown Unicast Storm Control

Web-Based GUI (Supports IPv4) • Smart Console Utility
